Ecophon Gedina E

Ecophon Gedina™ E has a recessed visible grid and a tegular edge design, creating a ceiling with a shadow effect that accentuates each tile and partially conceals the grid system. The visible surface of each tile is 7 mm below the grid. Each tile is easily demountable. Note that installation according to installation diagram M121 contributes to a higher live load capacity compared to M270. The system consists of Ecophon Gedina™ E tiles and Connect™ grid systems, with an approximate weight of 2,5 kg/m². The tiles are manufactured from high density glass wool. The visible surface has an Akutex™ T coating and the back of the tile is covered with glass tissue. The edges are painted. The grid is manufactured from galvanized steel. For best performance and system quality, use Connect™ grid and accessories

Product code : 56CEGE

The surface on Ecophon Gedina™ is Akutex™ T

Akutex™ T is a well-tried painted surface, that in combination with the glass wool core provides optimal sound absorption. It is a porous surface that allows almost 100% of the sound energy to penetrate into and be absorbed by the glass wool core. The surface is a crucial element in the system constituting a class A absorbent. The high light reflectance (84%) means that Akutex™ T can lead to cost-effective and more energy-efficient lighting.
